Installation and First Run
Install•Version 1.0.0•
This guide shows you how to install TaxisDB on Ubuntu on top of YottaDB
Step 1: Installing YottaDB
This is a full Installation of YottaDB including all plugins, if you want to customize your installation visit
Official Installation Guide of YottaDB
How to Install Octo
# Install prerequisite packages
# Ubuntu/Debian
sudo apt update
sudo apt install file binutils libelf-dev libicu-dev nano
# For Octo installation
sudo apt install bison build-essential ca-certificates cmake curl file flex git libconfig-dev libelf-dev libicu-dev libreadline-dev libssl-dev pkg-config
# For all plugins installation
sudo apt install libsodium-dev libcurl4-openssl-dev tcsh libgcrypt20-dev libgpg-error-dev libgpgme-dev gdb
# Download ydbinstall.sh script
wget https://download.yottadb.com/ydbinstall.sh
chmod +x ydbinstall.sh
# Install YottaDB with ALL plugins
sudo ./ydbinstall.sh --installdir /home/user/YottaDB --utf8 --verbose --allplugins --user user --group userYottaDB Environment Setup
The following environment variables must be set for Octo to operate properly:
ydb_distydb_gbldirydb_routinesydb_xc_ydbposix
The environment variablesydb_dist,ydb_gbldir,ydb_routines, andydb_xc_ydbposixcan initially be set by sourcingydb_env_setin your YottaDB installation directory.
# provides a detailed report on the YottaDB build, e.g.
yottadb -version
# Add the installdir of yottadb to the path
export PATH="$HOME/bin:/home/user/YottaDB:$PATH"
# Add the following line to the .bashrc
# to source the ydb_env_set each time we start a bash shell
# ydb_env_set uses reasonable defaults to set up a YottaDB application development environment that includes plugins conforming to the YottaDB standard (such as the POSIX plugin and Octo).
source /home/user/YottaDB/ydb_env_set
# The default environment is created under $ydb_dir, defaulting to `$HOME/.yottadb`
# defaulting to `$HOME/.yottadb` unless the environment variable `ydb_dir` points to another location,
# set this to define a directory for the environment set and managed by `ydb_env_set`. If it is not set, `ydb_env_set` uses `$HOME/.yottadb`.
echo $ydb_dir
# Points to the directory where YottaDB is installed.
echo $ydb_dist
# Points to a global directory file. A global directory file maps global variables (the hierarchical key-value relationships of the YottaDB database) to database files in the filesystem.
echo $ydb_gbldir
# Tells a process where to find application code written in M. It is not required by applications that do not invoke M code.
echo $ydb_routines
# Local repository for YottaDB databases
ln -s .yottadb/r2.02_x86_64/g/ YottaDB.dataWhen ydb_env_set is sourced, it provides a default execution environment (global directory and a default multi-region database) if none exists, and recovers an existing environment if needed. If neither gtmdir are defined, by default it creates the database in $HOME/.yottadb. The structure of the default environment is shown below, with routines in the r subdirectories, object code in the o and o/utf8 subdirectories. Databases are in the g subdirectory.
.yottadb
├── r
├── r1.36_x86_64
│ ├── g
│ │ ├── %ydbaim.dat
│ │ ├── %ydbaim.mjl
│ │ ├── %ydbocto.dat
│ │ ├── %ydbocto.mjl
│ │ ├── yottadb.dat
│ │ ├── yottadb.gld
│ │ └── yottadb.mjl
│ ├── o
│ │ └── utf8
│ └── r
└── V6.3-014_x86_64 -> r1.36_x86_64For more information refer to YottaDB Environment Setup
YottaDB CLI
How to start a YottaDB process
user@Z440:~/$ ydbInvestigate the path where you can run MUMPS code.
echo $ydb_routinesTest your installation
Create this M script at $HOME/.yottadb/r/env.m
init
WRITE !,"= YottaDB Environment Snapshot =",!
WRITE "YottaDB Release: ",$ZYRELEASE,!
WRITE "GT.M Version: ",$ZVERSION,!
WRITE "Build Date: ",$ZRELDATE,!
WRITE "Char Set: ",$ZCHSET,!
WRITE "PID: ",$JOB,!
WRITE "Mode: ",$ZMODE,!
WRITE "CWD: ",$ZDIRECTORY,!
WRITE "Global Dir: ",$ZGBLDIR,!
WRITE "Routines Path: ",$ZROUTINES,!
WRITE "Principal Dev: ",$PRINCIPAL,!
WRITE "Actual Dev: ",$ZIO,!
WRITE "Last Error: ",$ZSTATUS,!
ZSYSTEM "echo 'ydb_dist = '$ydb_dist"
ZSYSTEM "echo 'ydb_gbldir= '$ydb_gbldir"
ZSYSTEM "echo 'ydb_rout = '$ydb_routines"
QUITThen run it inside the ydb cli
YDB> DO init^env ; or D <subroutine>^<filename>
YDB> HALT ; or simply enter h to exit the consoleYottaDB GUI Server
How to start the web management application of YottaDB
yottadb -run %ydbgui --readwrite
Starting Server at port 9080 in directory /home/user/YottaDB/plugin/etc/ydbgui at logging level 0 in readwrite modeStep 2: Install TaxisDB
Download source code from
Install under your $HOME/.yottadb/r
First Run
Open YDB console and run
YDB> DO ^startThis will create the global directory structure (GLD) of TaxisDB on your machine. A new TaxisBase, i.e. the TaxisDB database will be created and then the script will run a few tests to populate database with some examples.
Expected Output
You should get a similar output
YDB>D ^start
*********************************************************************************
* TaxisDB — database engine licensed under SSPL v1.0 *
* TaxisBase — knowledge base licensed under ODbL v1.0 + DBCL v1.0 *
* *
* Copyright © 2026 Athanassios Hatzis - athanassios@healis.eu *
* All rights reserved except as granted by the applicable copy-left licenses *
* *
* THE SOFTWARE IS PROVIDED AS IS, WITHOUT WARRANTY OF ANY KIND. *
* *
* *
* WARNING: Existing data was found in TaxisDB database *
* A new TaxisDB will be generated and all existing data *
* currently stored will be PERMANENTLY DELETED and cannot be recovered *
* *
*********************************************************************************
Type YES to continue, or anything else to abort: YES
Confirmed. Proceeding with bootstrap...
<------ Create Objects obj.claudio_arrau and obj.tom_hanks ------>
======
obj.claudio_arrau
======
659be4427174eo4ibnti sys.attr.key obj.claudio_arrau
659be4427174eo4ibnti sys.attr.label Claudio Arrau @en
659be4427174eo4ibnti sys.attr.name claudio_arrau
659be4427174eo4ibnti sys.attr.alias ClaudioArrau
659be4427174eo4ibnti sys.attr.description Chilean pianist (1903-1991) @en
659be4427174eo4ibnti sys.attr.wikipage https://en.wikipedia.org/wiki/Claudio_Arrau
659be4427174eo4ibnti sys.attr.wikipage https://es.wikipedia.org/wiki/Claudio_Arrau
659be4427174eo4ibnti sys.attr.wikipage https://de.wikipedia.org/wiki/Claudio_Arrau
659be4427174eo4ibnti sys.attr.homepage https://arrauhouse.org/content/homepage.htm
659be4427174eo4ibnti sys.attr.isa sys.type.obj
======
obj.tom_hanks
======
659be4427195axrpan37 sys.attr.key obj.tom_hanks
659be4427195axrpan37 sys.attr.label Tom Hanks @en
659be4427195axrpan37 sys.attr.name tom_hanks
659be4427195axrpan37 sys.attr.alias TomHanks
659be4427195axrpan37 sys.attr.alias %TomHanks
659be4427195axrpan37 sys.attr.description American actor and filmmaker (born 1956) @en
659be4427195axrpan37 sys.attr.wikipage https://en.wikipedia.org/wiki/Tom_Hanks
659be4427195axrpan37 sys.attr.wikipage https://fr.wikipedia.org/wiki/Tom_Hanks
659be4427195axrpan37 sys.attr.wikipage https://el.wikipedia.org/wiki/Τομ_Χανκς
659be4427195axrpan37 sys.attr.isa sys.type.obj
=== Build Schema for a Movie Entity Type ===
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
<------ Create Movie Seven ------>
======
tt0011100
======
659be44279a520wb8zgm sandbox.movie.title Seven @en
659be44279a520wb8zgm sandbox.movie.genre thriller
659be44279a520wb8zgm sandbox.movie.genre mystery
659be44279a520wb8zgm sandbox.movie.releaseYear 1995
659be44279a520wb8zgm sandbox.movie.imdbid tt0011100
=== Build Schema for a Person Entity Type ===
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
<------ Create Person p.athan ------>
======
p.athan
======
659be4427f5a9bmovxki sys.attr.key p.athan
659be4427f5a9bmovxki sandbox.person.name athan
659be4427f5a9bmovxki sandbox.person.age 56
659be4427f5a9bmovxki sandbox.person.email athan@example.com
=== Build Schema for a DLC Item Type ===
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
ResolveIsaRef: resolving isa value 'sys.type.attr' for aid=299
<------ Create DLC Item 042 ------>
======
042
======
659be4428594bvncu5ef sandbox.dlc.id 042
659be4428594bvncu5ef sandbox.dlc.checkup Dilithium Crystals on 1st January 2013 @en
659be4428594bvncu5ef sandbox.dlc.count 100
659be4428594bvncu5ef sandbox.dlc.txdate 2013-01-01
======
042
======
eid aid tx valkey OP
659be4428594bvncu5ef 1009 7407 K3F1.018875 ( + )
659be4428594bvncu5ef 1010 7407 K3F2.018876 ( + )
659be4428594bvncu5ef 1011 7407 K3F3.018877 ( + )
659be4428594bvncu5ef 1012 7407 K3F4.018878 ( + )You can also see the user messages, at the INFO debug level, that have been recorded during the fist run
YDB> ZWRITE ^TXLOG ; or zwr ^TXLOG
YDB>zwr ^TXLOG
^TXLOG(2110458,1,1)="2026-08-23T22:19:42.335238 | apiWFL | INFO | StageRecordEND >>> staged <<< Total Records: 1"
^TXLOG(2110458,1,2)="2026-08-23T22:19:42.335616 | apiWFL | INFO | StageRecordEND >>> staged <<< Total Records: 2"
^TXLOG(2110458,1,3)="2026-08-23T22:19:42.335631 | API | INFO | Stage: processed 2 record(s) — 2 record(s) staged for ns=sandbox isBulkLoad=0"
^TXLOG(2110458,1,4)="2026-08-23T22:19:42.346839 | API | INFO | Transact: committed 2 records, tx=7401"
^TXLOG(2110458,1,5)="2026-08-23T22:19:42.352340 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 1"
^TXLOG(2110458,1,6)="2026-08-23T22:19:42.353727 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 2"
^TXLOG(2110458,1,7)="2026-08-23T22:19:42.357061 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 3"
^TXLOG(2110458,1,8)="2026-08-23T22:19:42.358384 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 4"
^TXLOG(2110458,1,9)="2026-08-23T22:19:42.361668 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 5"
^TXLOG(2110458,1,10)="2026-08-23T22:19:42.367585 | SAPI | INFO | Transact: committed 5 records, Total datoms written: 36, tx counter: 7402"
^TXLOG(2110458,1,11)="2026-08-23T22:19:42.368524 | apiWFL | INFO | StageRecordEND >>> staged <<< Total Records: 1"
^TXLOG(2110458,1,12)="2026-08-23T22:19:42.368539 | API | INFO | Stage: processed 1 record(s) — 1 record(s) staged for ns=sandbox isBulkLoad=0"
^TXLOG(2110458,1,13)="2026-08-23T22:19:42.373565 | API | INFO | Transact: committed 1 records, tx=7403"
^TXLOG(2110458,1,14)="2026-08-23T22:19:42.376809 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 1"
^TXLOG(2110458,1,15)="2026-08-23T22:19:42.378255 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 2"
^TXLOG(2110458,1,16)="2026-08-23T22:19:42.381500 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 3"
^TXLOG(2110458,1,17)="2026-08-23T22:19:42.385050 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 4"
^TXLOG(2110458,1,18)="2026-08-23T22:19:42.391136 | SAPI | INFO | Transact: committed 4 records, Total datoms written: 20, tx counter: 7404"
^TXLOG(2110458,1,19)="2026-08-23T22:19:42.391902 | apiWFL | INFO | StageRecordEND >>> staged <<< Total Records: 1"
^TXLOG(2110458,1,20)="2026-08-23T22:19:42.391919 | API | INFO | Stage: processed 1 record(s) — 1 record(s) staged for ns=sandbox isBulkLoad=0"
^TXLOG(2110458,1,21)="2026-08-23T22:19:42.396745 | API | INFO | Transact: committed 1 records, tx=7405"
^TXLOG(2110458,1,22)="2026-08-23T22:19:42.401102 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 1"
^TXLOG(2110458,1,23)="2026-08-23T22:19:42.402427 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 2"
^TXLOG(2110458,1,24)="2026-08-23T22:19:42.405695 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 3"
^TXLOG(2110458,1,25)="2026-08-23T22:19:42.409394 | sapiWFL | INFO | StageRecord: Succeeded — Total Records: 4"
^TXLOG(2110458,1,26)="2026-08-23T22:19:42.416236 | SAPI | INFO | Transact: committed 4 records, Total datoms written: 27, tx counter: 7406"
^TXLOG(2110458,1,27)="2026-08-23T22:19:42.417427 | apiWFL | INFO | StageRecordEND >>> staged <<< Total Records: 1"
^TXLOG(2110458,1,28)="2026-08-23T22:19:42.417452 | API | INFO | Stage: processed 1 record(s) — 1 record(s) staged for ns=sandbox isBulkLoad=0"
^TXLOG(2110458,1,29)="2026-08-23T22:19:42.422746 | API | INFO | Transact: committed 1 records, tx=7407"
^TXLOG(2110458,1,"CFG","LEVEL")=20
^TXLOG(2110458,1,"CFG","OUTPUT")=0
^TXLOG(2110458,1,"CFG","SEQ")=29
^TXLOG(2110458,1,"CFG","STARTED at")="2026-08-23T22:19:42.333942"
^TXLOG(2110458,1,"CFG","TRACE")=0
^TXLOG(2110458,"CURRENT")=1
^TXLOG(2110458,"SESSIONS")=1If you managed to get this output then everything works as expected and TaxisDB has been successfully installed on your machine.
TaxisDB keywords
The next thing you can do is to inspect all TaxisDB keywords and commands that have been added into YDB console environment. The first command to use is X PKW or EXECUTE PKW this is a shortcut alias for the full command which is DO Print^keywords. Here is the full list
YDB>X PKW
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
ALL KEYWORDS
~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
KEYWORD ALIAS
-----------------------------------------------------------------
=============
Executable Commands
=============
+ A
- R
DO Load^keywords KW
DO PrintSchema^sapi("sandbox") PS
DO PrintTBoxState^sapi TBS
DO Print^keywords PKW
DO Setup^logger("CRITICAL",1,0) CRITICAL
DO Setup^logger("DEBUG",1,0) DEBUG
DO Setup^logger("ERROR",1,0) ERROR
DO Setup^logger("INFO",1,0) INFO
DO Setup^logger("WARNING",1,0) WARNING
DO Transact^api TA
DO Transact^sapi TS
=============
location
=============
location.cvt.geo GEO
=============
obj
=============
obj.claudio_arrau ClaudioArrau
obj.tom_hanks TomHanks
%TomHanks
=============
sandbox
=============
sandbox.dlc.checkup checkup
sandbox.dlc.count count
sandbox.dlc.id dlcid
sandbox.dlc.txdate txdate
sandbox.movie.genre genre
sandbox.movie.imdbid imdb
sandbox.movie.releaseYear ry
sandbox.movie.title title
sandbox.movie.tmdbid tmdb
=============
sys
=============
sys.attr.abbr abbr
sys.attr.alias alias
sys.attr.cardinality cardin
sys.attr.description doc
sys.attr.display display
sys.attr.entattribute entattr
sys.attr.entspec entspec
sys.attr.entvalidationfn entvalidfn
sys.attr.example eg
sys.attr.exptype exptype
sys.attr.extid.code code
sys.attr.homepage home
sys.attr.id id
sys.attr.indexed ndx
sys.attr.isa isa
sys.attr.key key
sys.attr.label label
sys.attr.name name
sys.attr.notes notes
sys.attr.range range
sys.attr.required req
sys.attr.resolvedby rby
sys.attr.unique unq
sys.attr.usage use
sys.attr.validationfn validfn
sys.attr.wikipage wiki
sys.enum.cardinality CARDINALITY
sys.enum.cardinality.many MANY
sys.enum.cardinality.one ONE
sys.enum.unique UNIQUE
sys.enum.unique.insert UNQINSERT
sys.enum.unique.upsert UNQUPSERT
sys.type.assoc ASSOC
sys.type.attr ATYPE
sys.type.cvt CVT
sys.type.enum ENUM
sys.type.obj OBJ
sys.type.type TYPE
sys.type.val DTYPE
sys.val.alias ALIAS
sys.val.boolean BOOLEAN
sys.val.date DATE
sys.val.datetime DATETIME
sys.val.double DOUBLE
sys.val.fn FN
sys.val.geohash GEOHASH
sys.val.gps GPS
sys.val.integer INT
sys.val.keyword KEYWORD
sys.val.langstr LANGSTR
sys.val.name NAME
sys.val.point POINT
sys.val.pointz POINTZ
sys.val.ref REF
sys.val.string STRING
sys.val.time TIME
sys.val.timestamp TIMESTAMP
sys.val.url URL
sys.val.uuid4 UUID4
YDB>Aliases, i.e. TaxisDB keywords, is a very powerful and user friendly feature. Here is a quick demonstration:
YDB> D PE^api(TomHanks) ; or full command is: DO PrintEntity^api("obj.tom_hanks")
======
obj.tom_hanks
======
659be4427195axrpan37 sys.attr.key obj.tom_hanks
659be4427195axrpan37 sys.attr.label Tom Hanks @en
659be4427195axrpan37 sys.attr.name tom_hanks
659be4427195axrpan37 sys.attr.alias TomHanks
659be4427195axrpan37 sys.attr.alias %TomHanks
659be4427195axrpan37 sys.attr.description American actor and filmmaker (born 1956) @en
659be4427195axrpan37 sys.attr.wikipage https://en.wikipedia.org/wiki/Tom_Hanks
659be4427195axrpan37 sys.attr.wikipage https://fr.wikipedia.org/wiki/Tom_Hanks
659be4427195axrpan37 sys.attr.wikipage https://el.wikipedia.org/wiki/Τομ_Χανκς
659be4427195axrpan37 sys.attr.isa sys.type.objThe idea is to use keyword handles to access entities, i.e. TaxisDB objects, in a user friendly, memorable way and at the same time avoid quoted strings.
Next Steps
- Read Data Access API User Guides
- Read TaxisBase: The Database of TaxisDB
- View the code of test scripts that have been loaded during the first run
